cis-QTL analysis and GWAS integration workflow

Here we demonstrate the use of the pecotmr package to perform colocalization, TWAS and enrichment analysis between a pair of molecular QTL and GWAS using de-identified example data shipped with the package. All sample names, variant positions, and identifiers are synthetic.

Set up your environment

Load the pecotmr package.

library(pecotmr)

Load data

data(gwas_sumstats_example)
data(eqtl_region_example)
gwas <- gwas_sumstats_example
eqtl <- eqtl_region_example

head(gwas)

##           variant_id chrom      pos A1 A2    beta     se          z
## 1 chr22:32119788:T:C chr22 32119788  T  C -0.0089 0.0111 -0.8018018
## 2 chr22:32119867:T:G chr22 32119867  T  G -0.0089 0.0111 -0.8018018
## 3 chr22:32119961:T:G chr22 32119961  T  G  0.0236 0.0083  2.8433735
## 4 chr22:32120053:T:C chr22 32120053  T  C -0.0217 0.0246 -0.8821138
## 5 chr22:32120593:A:G chr22 32120593  A  G -0.0232 0.0246 -0.9430894
## 6 chr22:32120636:T:C chr22 32120636  T  C  0.0045 0.0141  0.3191489

names(eqtl)

## [1] "X"     "y_res"

head(eqtl$X[, 1:5])

##            chr22:32119788:T:C chr22:32119867:T:G chr22:32119961:T:G
## sample_001                  0                  0                  0
## sample_002                  0                  0                  1
## sample_003                  1                  1                  0
## sample_004                  1                  1                  1
## sample_005                  1                  1                  1
## sample_006                  1                  1                  1
##            chr22:32120053:T:C chr22:32120593:A:G
## sample_001                  0                  0
## sample_002                  0                  0
## sample_003                  0                  0
## sample_004                  0                  0
## sample_005                  0                  0
## sample_006                  0                  0

head(eqtl$y_res)

##  sample_001  sample_002  sample_003  sample_004  sample_005  sample_006
##  0.50197972  0.24567929 -0.06281688 -0.53649517 -0.56143407 -0.54624170

dim(eqtl$X)

## [1]  415 2828

Fine-mapping using SuSiE

library(susieR)
library(tidyverse)

## ── Attaching core tidyverse packages ──────────────────────── tidyverse 2.0.0 ──
## ✔ dplyr     1.2.0     ✔ readr     2.2.0
## ✔ forcats   1.0.1     ✔ stringr   1.6.0
## ✔ ggplot2   3.5.2     ✔ tibble    3.3.1
## ✔ lubridate 1.9.5     ✔ tidyr     1.3.2
## ✔ purrr     1.2.1
## ── Conflicts ────────────────────────────────────────── tidyverse_conflicts() ──
## ✖ dplyr::filter() masks stats::filter()
## ✖ dplyr::lag()    masks stats::lag()
## ℹ Use the conflicted package (<http://conflicted.r-lib.org/>) to force all conflicts to become errors

get_cs_index <- function(snps_idx, fitted_data) {
    idx <- tryCatch(
        which(
            pmap(list(a = fitted_data$sets$cs), function(a) snps_idx %in% a) %>% unlist()
        ),
        error = function(e) NA_integer_
    )
    if(length(idx) == 0) return(NA_integer_)
    return(idx)
}
signal_cutoff = 0.1
coverage = 0.7
susie_res <- susie(eqtl$X, eqtl$y_res,
                 L=20,
                 max_iter=500,
                 estimate_residual_variance=TRUE,
                 estimate_prior_variance=TRUE,
                 refine=TRUE,
                 compute_univariate_zscore=FALSE,
                 coverage=coverage)

secondary_coverage = 0.2
susie_res$sets_secondary = susie_get_cs(susie_res, eqtl$X, coverage=secondary_coverage)

compute_maf <- function(geno){
  f <- mean(geno,na.rm = TRUE)/2
  return(min(f, 1-f))
}
variants_index = c(which(susie_res$pip >= signal_cutoff), unlist(susie_res$sets$cs)) %>% unique %>% sort
maf = apply(eqtl$X, 2, compute_maf)[variants_index]
all_variants = colnames(eqtl$X)
variants = all_variants[variants_index]
pip = susie_res$pip[variants_index]
cs_info = map_int(variants_index, ~get_cs_index(.x, susie_res))
cs_index = ifelse(is.na(cs_info), 0, str_replace(names(susie_res$sets$cs)[cs_info], "L", "") %>% as.numeric)
univariate_res = univariate_regression(eqtl$X[, variants_index, drop=F], eqtl$y_res)
# here betahat and sebetahat were computed from standardized X and Y
susie_res$top_loci = cbind(variants, maf, univariate_res$betahat, univariate_res$sebetahat, pip, cs_index)
colnames(susie_res$top_loci) = c("variant_id", "maf", "bhat", "sbhat", "pip", "cs_index_primary")
rownames(susie_res$top_loci) = NULL

susie_res$top_loci

##       variant_id           maf                 bhat
##  [1,] "chr22:32596246:T:C" "0.278313253012048" "-0.122514739342209"
##  [2,] "chr22:32724254:T:C" "0.472289156626506" "0.146350893456887"
##  [3,] "chr22:32724508:C:A" "0.472289156626506" "0.146350893456887"
##  [4,] "chr22:32728910:G:A" "0.469879518072289" "0.146101325781137"
##  [5,] "chr22:32729588:T:C" "0.471084337349398" "0.145082188952344"
##  [6,] "chr22:32732510:G:A" "0.472289156626506" "0.147441999306526"
##  [7,] "chr22:32734332:A:G" "0.497590361445783" "0.14373324203229"
##  [8,] "chr22:32737583:C:T" "0.496385542168675" "0.142163759153291"
##  [9,] "chr22:32737848:A:G" "0.497590361445783" "0.14373324203229"
## [10,] "chr22:32740783:T:C" "0.497590361445783" "0.14373324203229"
## [11,] "chr22:32743285:A:C" "0.497590361445783" "0.14373324203229"
## [12,] "chr22:32745710:T:C" "0.473493975903614" "0.148379062725204"
## [13,] "chr22:32745749:T:C" "0.497590361445783" "0.141364354229342"
## [14,] "chr22:32752021:A:G" "0.49993728060858"  "0.141437506070959"
## [15,] "chr22:32755495:C:T" "0.474698795180723" "0.144921704020173"
##       sbhat                pip                  cs_index_primary
##  [1,] "0.0249868671221125" "0.144496972580007"  "0"
##  [2,] "0.0235695850612729" "0.0442663476368921" "1"
##  [3,] "0.0235695850612729" "0.0442663476368921" "1"
##  [4,] "0.0235890553342029" "0.0394962529670617" "1"
##  [5,] "0.0235285991106962" "0.0345101547646965" "1"
##  [6,] "0.0234182228577676" "0.0684513651989338" "1"
##  [7,] "0.0230653145891427" "0.066349051169566"  "1"
##  [8,] "0.0231535224323869" "0.0411110622935058" "1"
##  [9,] "0.0230653145891427" "0.066349051169566"  "1"
## [10,] "0.0230653145891427" "0.066349051169566"  "1"
## [11,] "0.0230653145891427" "0.066349051169566"  "1"
## [12,] "0.0234638029050504" "0.0769631005781234" "1"
## [13,] "0.0231007359525088" "0.0363654788619583" "1"
## [14,] "0.0230989526643856" "0.0363658594641679" "1"
## [15,] "0.0234421257080182" "0.0365496708560537" "1"

Top PIP variants:

sort(susie_res$pip, decreasing = TRUE)[1:5]

## chr22:32596246:T:C chr22:32745710:T:C chr22:32732510:G:A chr22:32734332:A:G
##         0.14449697         0.07696310         0.06845137         0.06634905
## chr22:32737848:A:G
##         0.06634905

TWAS

Use SuSiE weights,

R = cor(eqtl$X)

weights = susie_weights(susie_fit = susie_res)

twas_z(weights, gwas$z, R=R)

## $z
##          [,1]
## [1,] -3.07806
##
## $pval
##             [,1]
## [1,] 0.002083527

cor(eqtl$X%*%weights, eqtl$y_res)^2

##           [,1]
## [1,] 0.1220979

Now select only the top loci,

plot(weights)

weights[!all_variants %in% susie_res$top_loci[,1]] = 0

plot(weights)

twas_z(weights, gwas$z, R=R)

## $z
##           [,1]
## [1,] -2.438249
##
## $pval
##            [,1]
## [1,] 0.01475859

Use elastic net (alpha=0.5),

weights = glmnet_weights(eqtl$X, eqtl$y_res, alpha=0.5)
cor(eqtl$X%*%weights, eqtl$y_res)^2

##           [,1]
## [1,] 0.1484727

twas_z(weights, gwas$z, R=R)

## $z
##           [,1]
## [1,] -3.762025
##
## $pval
##              [,1]
## [1,] 0.0001685431

plot(weights)

Use LASSO,

weights = glmnet_weights(eqtl$X, eqtl$y_res, alpha=1)
cor(eqtl$X%*%weights, eqtl$y_res)^2

##           [,1]
## [1,] 0.2243896

twas_z(weights, gwas$z, R=R)

## $z
##           [,1]
## [1,] -4.475906
##
## $pval
##              [,1]
## [1,] 7.608779e-06

plot(weights)

Use mr.ash,

lasso.weights = glmnet_weights(eqtl$X, eqtl$y_res, alpha=1)
weights = mrash_weights(eqtl$X, eqtl$y_res, init_prior_sd=TRUE, beta.init=lasso.weights)

## Mr.ASH terminated at iteration 64: max|beta|=2.8638e-03, sigma2=1.0243e-01, pi0=0.9529

cor(eqtl$X%*%weights, eqtl$y_res)^2

##           [,1]
## [1,] 0.1872512

twas_z(weights, gwas$z, R=R)

## $z
##          [,1]
## [1,] -3.18897
##
## $pval
##             [,1]
## [1,] 0.001427806

plot(weights)

weights = mrash_weights(eqtl$X, eqtl$y_res, init_prior_sd=FALSE, beta.init=lasso.weights)

## Mr.ASH terminated at iteration 49: max|beta|=4.5259e-03, sigma2=1.0294e-01, pi0=0.9752

cor(eqtl$X%*%weights, eqtl$y_res)^2

##          [,1]
## [1,] 0.185201

twas_z(weights, gwas$z, R=R)

## $z
##           [,1]
## [1,] -3.299774
##
## $pval
##              [,1]
## [1,] 0.0009676273

plot(weights)

Enrichment analysis

data(gwas_finemapping_example)
data(qtl_finemapping_example)
gwas_path <- tempfile(fileext = ".rds")
qtl_path <- tempfile(fileext = ".rds")
saveRDS(gwas_finemapping_example, gwas_path)
saveRDS(qtl_finemapping_example, qtl_path)
xqtl_enrichment_wrapper(gwas_files = gwas_path, xqtl_files = qtl_path,
                        xqtl_finemapping_obj = c("context_1", "susie_result_trimmed"),
                        xqtl_varname_obj = c("context_1", "variant_names"))

## Warning in compute_qtl_enrichment(gwas_pip = dat$gwas_pip, susie_qtl_regions =
## dat$xqtl_data, : num_gwas is not provided. Estimating pi_gwas from the data.
## Note that this estimate may be biased if the input gwas_pip does not contain
## genome-wide variants.

## Estimated pi_gwas:  0.00141

## Warning in compute_qtl_enrichment(gwas_pip = dat$gwas_pip, susie_qtl_regions =
## dat$xqtl_data, : pi_qtl is not provided. Estimating pi_qtl from the data. Note
## that this estimate may be biased if either 1) the input susie_qtl_regions does
## not have enough data, or 2) the single effects only include variables inside of
## credible sets or signal clusters.

## Estimated pi_qtl:  0.00071

## Fine-mapped GWAS and QTL data loaded successfully for enrichment analysis!
## Proportion of xQTL missing from GWAS variants: 0 in MI round 0
## Proportion of xQTL missing from GWAS variants: 0 in MI round 1
## Proportion of xQTL missing from GWAS variants: 0 in MI round 2
## Proportion of xQTL missing from GWAS variants: 0 in MI round 3
## Proportion of xQTL missing from GWAS variants: 0 in MI round 4
## Proportion of xQTL missing from GWAS variants: 0 in MI round 5
## Proportion of xQTL missing from GWAS variants: 0 in MI round 6
## Proportion of xQTL missing from GWAS variants: 0 in MI round 7
## Proportion of xQTL missing from GWAS variants: 0 in MI round 8
## Proportion of xQTL missing from GWAS variants: 0 in MI round 9
## Proportion of xQTL missing from GWAS variants: 0 in MI round 10
## Proportion of xQTL missing from GWAS variants: 0 in MI round 11
## Proportion of xQTL missing from GWAS variants: 0 in MI round 12
## Proportion of xQTL missing from GWAS variants: 0 in MI round 13
## Proportion of xQTL missing from GWAS variants: 0 in MI round 14
## Proportion of xQTL missing from GWAS variants: 0 in MI round 15
## Proportion of xQTL missing from GWAS variants: 0 in MI round 16
## Proportion of xQTL missing from GWAS variants: 0 in MI round 17
## Proportion of xQTL missing from GWAS variants: 0 in MI round 18
## Proportion of xQTL missing from GWAS variants: 0 in MI round 19
## Proportion of xQTL missing from GWAS variants: 0 in MI round 20
## Proportion of xQTL missing from GWAS variants: 0 in MI round 21
## Proportion of xQTL missing from GWAS variants: 0 in MI round 22
## Proportion of xQTL missing from GWAS variants: 0 in MI round 23
## Proportion of xQTL missing from GWAS variants: 0 in MI round 24
## EM updates completed!

## [[1]]
## [[1]]$`Alternative (coloc) p1`
## [1] 0.001413425
##
## [[1]]$`Alternative (coloc) p12`
## [1] 1.000238e-06
##
## [[1]]$`Alternative (coloc) p2`
## [1] 0.0007061743
##
## [[1]]$`Effective MI rounds`
## [1] 24
##
## [[1]]$`Enrichment (no shrinkage)`
## [1] -7.950053
##
## [[1]]$`Enrichment (w/ shrinkage)`
## [1] -7.953252e-06
##
## [[1]]$Intercept
## [1] -6.559616
##
## [[1]]$`sd (intercept)`
## [1] 0.5002662
##
## [[1]]$`sd (no shrinkage)`
## [1] 999.7984
##
## [[1]]$`sd (w/ shrinkage)`
## [1] 0.9999995
##
##
## $unused_xqtl_variants
## $unused_xqtl_variants[[1]]
## NULL

Anqi Wang and Gao Wang

2026-03-01

Set up your environment

Load data

Fine-mapping using SuSiE

TWAS

Enrichment analysis
